Specification

Nominal Impedance
- 8 ohms

Recommended Amplifiers
- 20 to 150 watts

Frequency Response
- 30Hz-30kHz

Sensitivity
- 88.5 dB linear for 1 watt at 1 metre

Bass /midrange
- ProAc 165mm (6.5”) ProAc unit with Excel magnet system, glass fibre wave cone and copper phase plug.

Dome tweeter option D2D
- ProAc 25mm (1”) silk dome air cooled and inner damping. Mirror image offset.

Ribbon tweeter option D2R
- The ProAc ribbon tweeter has a ribbon lighter than a human hair with rear chamber damping and alnico magnet.

Crossover
- Finest components on dedicated circuit board. Multistrand oxygen free copper cable throughout. Split for optional Bi wiring or Bi amplification

Height (Cabinet)
- 430mm (17”)

Width (Cabinet)
- 203mm (8”)

Depth (Cabinet)
- 260mm (10.25”) including grill thickness of 12mm

Weight
- each 11Kg (24lb)

Mode
- Stand mounting

Grille
- Acoustically transparent crimplene

Standard Finishes
- Black Ash, Mahogany, Cherry, Walnut, Oak.

Premium Finishes
- Rosewood, Ebony. *Premium Finishes to order at extra cost*
