All measurements are made at 120V / 240V //50Hz / 60Hz
Amplifier section

CLIPPING POINT OF THE PREAMPLIFIER IS SET TO A LEVEL WHERE TOTAL HARMONIC DISTORTION

(THD) IS 0.2%

Input Impedance (Fixed) 330 kohm
Output Impedance (20 Hz-20kHz) < 0,01 Ohm
Frequency response (DC - 65 kHz) - 3 dB
Input level for rated output 1 V RMS
Max. peak current > 150 A
THD(measured at 1 kHzhalf power,8W) < 0,006 %
THD (measured at 1 kHz -1 dB, 8 W) < 0,007 %
Noise
(measured with both inputs shorted) 400 Hz - 30 kHz : 130 µV
DC - 30 kHz : 200 µV



Rated output power

8 ohms 400
4 ohms 765
2 ohms 1010


Power consumption (no load or signal) 230 W

Dimensions
Width
358 mm /

14.1 inches
Depth
470 mm /

18.5 inches
Height
261 mm /

10.2 inches
Weight 25 kg. / 55 lbs.
