Frequency Response

90 Hz — 35 kHz

Sensitivity (1W@1M)

87 dB

Nominal Impedance

6 ohms

Power Handling (RMS)

75 W

System Power Handling (RMS)

100 W

Recommended Amplifier Requirements

30 — 100 W

Maximum SPL

106 dBa

Bass Alignment

C:Bass reflex - Front ported L/R:Bass reflex - Side ported

Drive Unit Complement

3 x 4" (100 mm) C-CAM cone bass/mid driver
3 x 1" (25 mm) C-CAM Gold Dome tweeter

Cabinet Dimensions (H x W x D)

175 x 980 x 67 mm (67/8 x 389/16 x 25/8")

Cabinet Dimensions (Including Grille and Terminals (H x W x D))

175 x 980 x 79 mm (67/8 x 389/16 x 31/8")

Cabinet Dimensions (Including Grille and Bracket (H x W x D))

175 x 980 x 84 mm (67/8 x 389/16 x 35/16")

Pre-Construction Bracket

Dedicated bracket included

Weight

7.4 kg (16 lb 4 oz)

Sold As

Single Unit
