Frequency Response

80 Hz — 35 kHz

Sensitivity (1W@1M)

83 dB

Nominal Impedance

8 ohms

Power Handling (RMS)

75 W

System Power Handling (RMS)

100 W

Recommended Amplifier Requirements

30 — 100 W

Maximum SPL

102 dBa

Bass Alignment

Bass reflex - Rear ported

Drive Unit Complement

1 x 4" (100 mm) C-CAM cone bass/mid driver
1 x 1" (25 mm) C-CAM Gold Dome tweeter

Cabinet Dimensions (H x W x D)

198 x 125 x 140 mm (713/16 x 415/16 x 51/2")

Cabinet Dimensions (Including Grille and Terminals (H x W x D))

198 x 125 x 164 mm (713/16 x 415/16 x 67/16")

Cabinet Dimensions (Including Grille and Bracket (H x W x D))

198 x 125 x 203 mm (713/16 x 415/16 x 8")

Pre-Construction Bracket

Optional - Monitor Audio Speaker Mount (MASM)

Weight

2.1 kg (4 lb 10 oz)

Sold As

Pair
