System Format
3-way

Sensitivity (2.83v @ 1m, Free-Field)
86.5 dB

Sensitivity (2.83v @ 1m, Installed)
N/A

Recommended Amplifier Power (RMS into 4 Ohm, Music Signal)
130 – 500 W

Continuous Power Handling (CTA 426-B)
250 W

Nominal Impedance
4 Ohms

Minimum Impedance (20Hz to 20kHz)
3.9 Ohms @ 140 Hz

Drive Unit Complement
1 x 8” (203 mm) HDT C-CAM Bass Drivers
1 x 3” (76 mm) HDT C-CAM Mid-Range Driver
1 x MPD III Tweeter

Frequency Response Free-Field (-6dB)
49 Hz – 60 kHz

Frequency Response, In-Room (-6dB)
32 Hz – 60 kHz

Maximum Peak SPL (AES75, Z-weighted)
119 dB

Bass Alignment
HiVe II Ported

Port Tuning Frequency
38 Hz

Crossover Frequency
LF/MF: 700 Hz
MF/HF: 2.6 kHz

External Dimensions with all accessories fitted (H x W x D)
447.7 x 230 x 357.3 mm (1715/8 x 91/16 x 141/16”)

Weight (each)
14 kg (30 lb 14 oz)

Sold As
Pair
